How to Log In to a Ruijie Switch

Logging into a Ruijie switch is the first step in configuring and managing your network infrastructure. In particular, when you log in for the first time, access the switch through the intuitive web interface (GUI). It is also accessible for ongoing maintenance. You can also use the command-line interface (CLI) via console or SSH. This guide outlines the different methods you need to log in to a Ruijie switch quickly and securely.

Option 1: Login via Web GUI (Browser)

To manage a Ruijie switch, you need to first log in. You can use either the Web interface (GUI) or the Command-Line Interface (CLI). The method you choose depends on the model and your network environment. This guide covers both approaches for initial setup and ongoing administration.

Step-by-Step:

1. Connect to the Switch:
   • Plug a laptop or PC into any Ethernet port on the switch.
   • Set your PC’s IP to be on the same subnet as the switch’s default IP (usually. 192.168.1.254).
2. Access the Web GUI:
   • Open a browser and enter:
     http://192.168.1.254
   • Press Enter.
3. Log In:
   • Default username: admin
   • Default password: admin Or sometimes blank (depends on the model and firmware).
   • After logging in, be sure to change the password immediately for security.
4. Start Configuration:
   • You’ll be taken to the dashboard, where you can manage VLANs, IPs, cloud settings, etc.

🔒 Tip: If the web interface doesn’t open, try checking:

• PC IP settings.
• Cable connection.
• Switch port status.
• Use ping 192.168.1.254 to confirm connectivity.

Option 2: Login via CLI (SSH)

Method A: Use Console Cable

For the (First-Time Setup or Offline Device)

1. Connect Console Cable:
   • Use a console cable (RJ45-to-USB or DB9) to connect the switch’s console port to your PC.
2. Open Terminal Software:
   • Use PuTTY, Tera Term, or SecureCRT.
   • Set serial connection settings:
     • Baud rate: 9600
     • Data bits: 8
     • Stop bits: 1
     • Parity: None
     • Flow control: None
3. Log In:
   • You’ll see a login prompt: Username: admin Password: admin

Method B: SSH (Over Network)

1. Make sure the switch has an IP address on a reachable network.
2. Use SSH Client (like PuTTY or Terminal):

ssh admin@192.168.1.254

3. Enter Password:
   The default password is admin, unless changed.

What to Do After Login

• After you log in to the Ruijie switch, change the default credentials: username admin password YOUR_NEW_PASSWORD
• Configure hostname, VLANs, IP interfaces, cloud access, etc.
• Save configuration: write

✅ Conclusion

Logging into a Ruijie switch is straightforward. You can log in to a Ruijie switch using the web GUI. This method is easy to use. Alternatively, initiate a login via CLI for advanced configuration. For initial setup, start with the console or direct connection. Once configured, SSH or cloud access makes ongoing management more convenient.

Accessing your Ruijie switch via the web GUI or CLI gives you full control over network configurations. It also allows for firmware updates, VLAN management, and cloud integration. By following the proper login steps, you ensure a smooth setup and secure management process. Once logged in, remember to update default credentials and save your configuration changes to maintain network security and stability.
